Fixing 502 Bad Gateway Errors in Docker Compose When Uploading Big Files to FastAPI

Troubleshooting Docker 502 Errors during File Upload

When working with FastAPI, Docker Compose, and file uploads, you may occasionally encounter errors, particularly with large file uploads. A common issue reported by developers is a 502 Bad Gateway error, especially when trying to upload larger files, such as a 120MB .7z archive.

This type of error can result from multiple causes, including server timeouts, configuration limits in Docker, or even reverse proxy issues like those encountered with Nginx. Understanding the root cause is key to resolving these persistent upload problems.

If you're using FastAPI's Swagger UI for uploads, you might notice the application attempting to refresh or crash during the process, especially with smaller file uploads. These symptoms can lead to inconsistent behavior and require further debugging.

In this guide, we’ll dive into what could be causing these errors, including file size limits, reverse proxy misconfigurations, or other backend issues in your Docker Compose environment. We’ll also explore potential solutions to prevent recurring errors when dealing with file uploads in FastAPI applications.

Understanding the Solution for 502 Error in FastAPI with Docker Compose

The scripts provided earlier aim to tackle the issue of uploading large files, specifically a 120MB .7z archive, via FastAPI and Docker Compose. One of the core elements is the use of background tasks in FastAPI. By leveraging the background_tasks.add_task() command, the file extraction process is handled asynchronously, meaning it doesn’t block the main request cycle. This is essential for preventing timeout errors when processing large files. Without this feature, FastAPI would try to handle everything in the main thread, likely causing a 502 Bad Gateway error if the server takes too long to respond.

Another key feature is the use of the shutil.copyfileobj() method, which efficiently writes the uploaded file to disk. This function is designed for large files since it reads from the file stream in chunks, preventing memory overload. The UUID function in Python ensures that each file gets a unique name to prevent overwriting, which is important in environments where multiple users may upload files simultaneously. If a file name isn’t unique, you could face issues with file corruption or conflicts during the upload process.

The Docker Compose file is configured to extend the timeout for the FastAPI server using the uvicorn --timeout-keep-alive option. This command ensures that the server can maintain a connection with the client longer, even when large files take a significant time to upload. By setting this to 300 seconds (or 5 minutes), it prevents Docker from closing the connection prematurely, which often results in the 502 error. It also helps in maintaining stability during long-running processes.

Lastly, the Nginx configuration plays a critical role in allowing larger file uploads by setting the client_max_body_size directive to 200MB. This change ensures that Nginx can accept files larger than the default limit of 1MB. Coupled with the proxy_read_timeout directive, which allows the server to wait longer for the backend server’s response, these settings help avoid errors that stem from slow or large file transfers. Together, these optimizations ensure that your FastAPI application can handle large file uploads without crashing or causing 502 errors in Docker Compose environments.

# This FastAPI function handles large file uploads using background tasks.
from fastapi import FastAPI, UploadFile, File, BackgroundTasks, HTTPException, status
import os, shutil, uuid
from fastapi.responses import JSONResponse
app = FastAPI()
UPLOAD_DIR = "/app/uploads"
@app.post("/7zip/")
async def upload_7zip(background_tasks: BackgroundTasks, archive_file: UploadFile = File(...)):
    # Check if the uploaded file is a valid .7z file
    if not archive_file.filename.endswith(".7z"):
        raise HTTPException(status_code=status.HTTP_400_BAD_REQUEST, detail="Please upload a valid 7z file.")
    # Generate a unique filename to prevent overwrites
    archive_filename = f"{uuid.uuid4()}_{archive_file.filename}"
    archive_path = os.path.join(UPLOAD_DIR, archive_filename)
    try:
        # Save the uploaded file to the server
        with open(archive_path, "wb") as buffer:
            shutil.copyfileobj(archive_file.file, buffer)
        # Add file extraction to background tasks to avoid timeouts
        background_tasks.add_task(extract_file, archive_path)
        return JSONResponse({"message": "File uploaded successfully, extraction is in progress."})
    except Exception as e:
        raise HTTPException(status_code=500, detail=f"An error occurred while processing the 7z file: {str(e)}")
# Background task to extract files
def extract_file(archive_path: str):
    # Placeholder function for extracting 7z files
    pass

# Adjusting Nginx configuration to allow larger file uploads
server {
    listen 80;
    server_name example.com;
    location / {
        proxy_pass http://app:8000;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }
    # Set the maximum allowed upload size to 200MB
    client_max_body_size 200M;
    proxy_read_timeout 300;
}

# Docker Compose file with increased timeout to avoid 502 errors
version: '3'
services:
  app:
    container_name: fastapi_app
    build: .
    command: bash -c "uvicorn main:app --host 0.0.0.0 --port 8000 --timeout-keep-alive=300"
    ports:
      - "8000:8000"
    volumes:
      - ./uploads:/app/uploads
    depends_on:
      - db
    restart: always
    environment:
      - FASTAPI_ENV=production
  db:
    image: postgres
    environment:
      POSTGRES_USER: user
      POSTGRES_PASSWORD: pass

Overcoming File Size Issues in FastAPI with Docker Compose

One important aspect that can affect file uploads in Docker Compose environments is the handling of server limits for memory and timeouts. In addition to server timeout adjustments and reverse proxy configurations, file uploads can also be impacted by system-level constraints, such as available memory and CPU resources. When uploading a large file, like a 120MB .7z archive, the server may run into memory exhaustion or high CPU utilization, causing it to crash or refresh mid-process. This can be further exacerbated when multiple users are uploading files simultaneously.

Another crucial point is that file upload performance may degrade due to containerization itself. Docker isolates resources per container, meaning that unless configured properly, a container may not have sufficient resources to handle large files efficiently. This can lead to the server refreshing or crashing when handling even smaller files, such as the 16-17 MB range you've experienced. It is essential to ensure that your Docker containers have the necessary CPU and memory resources allocated, and the limits should be tested in real-world scenarios.

Lastly, FastAPI’s request handling can be optimized using streaming techniques, which allow for chunked file uploads. This would help handle larger files without overwhelming the server’s memory. Combined with the proper configuration of Nginx, Uvicorn, and Docker resource allocations, streaming can make your API more robust. Incorporating these additional optimizations ensures better stability when dealing with large or concurrent file uploads in production environments.
