Email Notification Service Placement in ASP.NET Core Through Onion Architecture

Understanding Service Layer Roles in Onion Architecture

Understanding where to position different features is essential when creating an application with the onion architecture, particularly in the context of ASP.NET Core. By dividing the program into multiple layers, each with a specific role, the onion architecture highlights a distinct division of responsibilities. The application layer, which forms the basis of application operations, is mostly focused on business logic and use cases. By separating business rules from external frameworks and technologies, this structure adheres to the principles of clean architecture.

However, features that communicate with external systems, such email notifications, might occasionally make it difficult to distinguish between different layers. These are usually regarded as a component of the Infrastructure layer, which manages all interactions with outside systems and puts the interfaces specified by the Application layer into practice. The idea of keeping business logic and external system interactions apart is supported by the Infrastructure layer's placement of email services, which helps to maintain an organized and manageable codebase that complies with the rules of the onion architecture.

Examining ASP.NET Core's Email Service Implementation

The aforementioned scripts demonstrate how to incorporate an email notification service into an ASP.NET Core application that adheres to the Onion Architecture. Because email servers are interfaced with other systems using SMTP, the email notification functionality in this architecture is located in the Infrastructure layer. The actions required to send emails are all encapsulated in the EmailService class. The core program will stay independent of the particular email sending techniques, which can change and be changed as needed without affecting other system components thanks to this separation. Email communications are managed by the EmailService class via the SmtpClient from the.NET framework. It offers an asynchronous SendEmailAsync function that uses a SmtpClient object to create and send emails while requiring the recipient's address, email subject, and message as inputs.

Calls to the EmailService are made within the Presentation layer, which is usually managed by controllers in an ASP.NET Core MVC or API project. This is demonstrated in the example where a message is successfully sent using the UserService, at which point the EmailService is called. This design adheres to the principles of clean architecture by keeping concerns apart and enabling the decoupling of the email sending process from user message handling. Testing and maintenance are made easier by the introduction of interfaces like IEmailService, which further isolates the implementation details and permits dependency injection. This approach not only maintains the system's flexibility but also enhances its scalability by confining external service interactions to specific, interchangeable components.

public class EmailService : IEmailService
{
    private readonly SmtpClient _smtpClient;
    public EmailService(SmtpClient smtpClient)
    {
        _smtpClient = smtpClient;
    }
    public async Task SendEmailAsync(string recipient, string subject, string message)
    {
        var mailMessage = new MailMessage("noreply@example.com", recipient, subject, message);
        await _smtpClient.SendMailAsync(mailMessage);
    }
}

public interface IEmailService
{
    Task SendEmailAsync(string recipient, string subject, string message);
}
public interface IUserService
{
    Task<bool> SendMessage(User recipient, string messageText);
}
public class UserService : IUserService
{
    private readonly IEmailService _emailService;
    public UserService(IEmailService emailService)
    {
        _emailService = emailService;
    }
    public async Task<bool> SendMessage(User recipient, string messageText)
    {
        // Additional logic for sending a message
        await _emailService.SendEmailAsync(recipient.Email, "New Message", messageText);
        return true;
    }
}

Architectural Issues with ASP.NET Core Email Notifications

The onion architecture used in an ASP.NET Core application to position email notifications presents important questions regarding software design and architecture principles. High degrees of decoupling between an application's layers are maintained by the onion architecture, ensuring that modifications to external frameworks and tools have little effect on the essential business logic. This idea is upheld by placing the email notification service inside the Infrastructure layer, which separates business rules from external communication. By enabling developers to change or replace external communication details without impacting other areas of the application, this layering aids in preserving the scalability of the application.

This design approach improves the application's flexibility to accommodate new business needs or technological advancements while also making maintenance easier. For example, only the Infrastructure layer's implementation needs to be altered if the decision is made to switch email service providers; the Application and Presentation layers stay unchanged. Additionally, the application can create extra services like logging and error handling around the email sending process by isolating the email service within the Infrastructure layer. These services can be vital for troubleshooting and keeping an eye on the behavior of the application in production scenarios.
