How to Use the Unified Vitis IDE with Git

Getting Started with Git in Vitis IDE

Compared to the previous Eclipse-based version, using Git with the new "Unified Vitis" IDE—which is based on VSCode—presents different issues. The most recent version lacks the import/export project wizard, which makes it impossible to properly manage version control.

This article attempts to solve the problems that come up when using Git in Vitis, such as how to handle files that are generated with absolute paths and how to facilitate seamless collaboration between various development systems. We'll look at a useful workflow for using Git to effectively manage your Vitis projects.

Describe the Scripts for Vitis Automation

The first script uses Python to automate the Vitis project setup. Importing the required modules, namely vitis and os, is the first step. Next, it uses os.makedirs() to define the root path and, if it doesn't already exist, to construct the build directory. The script configures the primary source directory and the anticipated paths for the XSA file. It then sets the workspace to the newly formed build directory and generates a Vitis client. Using client.create_platform_component(), the platform component is constructed, indicating the CPU configuration, OS, and hardware. An application component is made and connected to the platform component once the platform component has been constructed. Ultimately, the component is constructed after the required files are imported into the Vitis project.

The Vitis project is initialized and Git integration is set up by the second script, which is a shell script. The build directory and root path are defined, and if the directory doesn't already exist, it is created. After that, the script uses vitis -s tools/build_app.py to run the Python script and automate the project setup. The Python script executes, and then the shell script creates a Git repository by going to the root directory, adding build directories to the .gitignore file, and initializing Git using git init. After staging the pertinent files with git add, git commit -m is used to commit them to the repository. With this method, version control is maintained for the project files that are required, but the build folders are kept out of it.

import vitis
import os

ROOT_PATH = os.path.abspath(os.path.dirname(__file__))
VITIS_BUILD_DIR_PATH = os.path.join(ROOT_PATH, "build-vitis")
os.makedirs(VITIS_BUILD_DIR_PATH, exist_ok=True)
EXPECTED_XSA_FILE_PATH = os.path.join(ROOT_PATH, "build-vivado", "mydesign.xsa")
COMPONENT_NAME = "MyComponent"
MAIN_SRC_PATH = os.path.join(ROOT_PATH, "src")

client = vitis.create_client()
client.set_workspace(path=VITIS_BUILD_DIR_PATH)

PLATFORM_NAME = "platform_baremetal"
platform = client.create_platform_component(
    name=PLATFORM_NAME,
    hw=EXPECTED_XSA_FILE_PATH,
    os="standalone",
    cpu="mycpu"
)

platform = client.get_platform_component(name=PLATFORM_NAME)
status = platform.build()

comp = client.create_app_component(
    name=COMPONENT_NAME,
    platform=os.path.join(VITIS_BUILD_DIR_PATH, PLATFORM_NAME, "export", PLATFORM_NAME, f"{PLATFORM_NAME}.xpfm"),
    domain="mydomainname"
)

comp = client.get_component(name=COMPONENT_NAME)
status = comp.import_files(
    from_loc=MAIN_SRC_PATH,
    files=["CMakeLists.txt", "UserConfig.cmake", "lscript.ld", "NOTUSED.cpp"],
    dest_dir_in_cmp="src"
)

comp.build()

#!/bin/bash

ROOT_PATH=$(pwd)
VITIS_BUILD_DIR_PATH="$ROOT_PATH/build-vitis"
mkdir -p "$VITIS_BUILD_DIR_PATH"
EXPECTED_XSA_FILE_PATH="$ROOT_PATH/build-vivado/mydesign.xsa"
COMPONENT_NAME="MyComponent"
MAIN_SRC_PATH="$ROOT_PATH/src"

vitis -s tools/build_app.py

# After running the Python script, set up Git repository
cd "$ROOT_PATH"
git init
echo "build-vitis/" >> .gitignore
echo "build-vivado/" >> .gitignore
git add src/ tools/ .gitignore
git commit -m "Initial commit with project structure and scripts"

# Script end

Understanding Version Control and the Vitis IDE

Understanding the components and structure of Vitis projects is one of the requirements for using the new "Unified Vitis" IDE with Git. Version management is complicated by the massive number of files generated by the Vitis IDE, many of which have absolute paths. These files contain metadata unique to the IDE, device descriptions, and platform parameters. Without appropriate handling, version control of these files can lead to problems for developers, such as build errors from mismatched paths on various systems.

It's standard practice to remove folders maintained by Vitis from version control in order to lessen these issues. Rather, important configuration files like CMake files, linker scripts, and other project files are manually transferred to the locations Vitis expects them to be. By ensuring that only the files that are required are version-controlled, this method lowers the possibility of errors and conflicts while working with other developers. Furthermore, this procedure can be streamlined by employing automation scripts, such as Python or shell scripts, which provide consistent and repeatable project setup and file management.

Crucial Elements of Effective Version Control in the Vitis IDE

There are a few essential steps involved in implementing version control with the new Unified Vitis IDE. To start preventing conflicts and mistakes, start by removing directories created by Vitis from version control. Rather, concentrate on maintaining track of CMake files, linker scripts, and other important project components. This procedure can be greatly streamlined by automation scripts, especially those written in Python, which can automate project setup and make sure all required files are in the right places.

You may guarantee a consistent development environment across several systems by automating the setup, which lowers the possibility of path-related problems. This method makes project management easier while also promoting more seamless developer collaboration. Furthermore, version control and editing are made simpler by leaving the source files in their original locations and pointing CMake to them, all without having to deal with the difficulties of handling Vitis's internal file structures.
