Resolving Derived Column Conversion Errors in SSIS: DTS_E_INDUCEDTRANSFORMFAILUREONERROR

Understanding SSIS Derived Column Conversion Errors

Imagine you're working on an SSIS package to handle data transformation tasks, aiming to streamline data flow and ensure accuracy for a smooth database integration. But, as soon as you add a derived column to convert data types, you run into an unexpected error: DTS_E_INDUCEDTRANSFORMFAILUREONERROR. This error can be frustrating, especially if you're converting a simple postcode field.

The error message, "[Derived Column [2]] Error: SSIS Error Code DTS_E_INDUCEDTRANSFORMFAILUREONERROR," indicates that the derived column transformation failed due to a conversion problem. Often, the issue arises when transforming one data type to another, like converting text postcodes to integers.

For example, if your staging data table stores postcodes as integers and you try to cast or manipulate them with (DT_I4) postcode in SSIS, the SSIS engine may fail if it encounters non-integer data. This could occur when blank values or unexpected formats enter the postcode column, which SSIS then can't process correctly. 🛠️

In this article, we’ll break down common causes of this error and explore strategies to resolve it. From handling null values to configuring error outputs, you'll learn how to keep your SSIS package running smoothly, even with data conversion hurdles. Let’s dive into the solutions!

Handling Derived Column Transformation Errors in SQL Server

The scripts above are designed to address the common SSIS error, DTS_E_INDUCEDTRANSFORMFAILUREONERROR, which arises when converting data in a derived column transformation. When using SQL Server Integration Services (SSIS) to integrate data, one common task is converting a string to an integer, such as a postcode. However, if the conversion encounters unexpected formats like empty or non-numeric values, the process fails, causing this error. To prevent this, the solution includes using a stored procedure in SQL Server to handle the conversion, which checks the input data's validity before attempting any transformation. By employing commands like ISNUMERIC and TRY...CATCH blocks, the script identifies and manages invalid data upfront, ensuring the SSIS package runs smoothly. Imagine, for example, a scenario where a company’s postcode data comes from multiple regions, leading to various formats. This stored procedure script would allow the system to validate and safely convert these values without causing errors in data integration pipelines. 📊

The stored procedure begins by declaring variables and utilizing ISNUMERIC to confirm that each postcode is, in fact, a numeric value. This check is critical to avoid attempts to convert non-numeric values into an integer, which would result in an error. Within the TRY...CATCH block, RAISERROR provides custom error messages when invalid values are detected, alerting the developer or data engineer about problematic records. This design prevents failures and flags entries that may need correction or review, adding a layer of transparency to the process. This way, rather than the process failing silently, errors are exposed and can be handled appropriately. For example, if a postcode in the database reads "AB123," the RAISERROR command would trigger, providing information on why the transformation cannot proceed, and allowing for a quick resolution. 🛠️

In addition, the SSIS package itself includes a transformation expression that manages values and non-numeric data before conversion. This transformation, using a derived column, checks for values and assigns a default value of 0 if any are found. If the postcode isn’t , it verifies its numeric status using ISNUMERIC before proceeding with the conversion to an integer. This modular approach of validation followed by transformation minimizes potential interruptions by filtering out problematic data at the start of the pipeline. For example, if a dataset contains empty postcode fields, these will be filled with a zero by default, keeping the package running smoothly and avoiding the hassle of stopping to manually inspect each blank field.

The cursor-based unit test script further validates this setup by simulating multiple test cases in SQL Server, helping to ensure that each function of the stored procedure works as expected. The unit test runs through various postcode formats, from null values to purely numeric strings, allowing the development team to see how each input behaves under the procedure’s rules. If a postcode passes validation, it’s logged as "Valid"; if it fails, it’s marked "Invalid" and the issue is raised in the system. This process provides a safety net for testing and enhances reliability in production environments, reducing downtime and improving data accuracy.

-- This solution uses a stored procedure in SQL Server to manage postcode data conversion.
-- It includes checks for invalid entries and ensures data conversion safety.
-- Suitable for scenarios where postcodes may have null or non-integer values.
CREATE PROCEDURE sp_HandlePostcodeConversion
@InputPostcode NVARCHAR(10)
AS
BEGIN
    -- Error handling block to check conversion feasibility
    BEGIN TRY
        DECLARE @ConvertedPostcode INT;
        -- Attempt conversion only if data is numeric
        IF ISNUMERIC(@InputPostcode) = 1
        BEGIN
            SET @ConvertedPostcode = CAST(@InputPostcode AS INT);
        END
        ELSE
        BEGIN
            RAISERROR('Invalid postcode format.', 16, 1);
        END
    END TRY
    BEGIN CATCH
        PRINT 'Error in postcode conversion: ' + ERROR_MESSAGE();
    END CATCH;
END;

-- To use this solution, open SSIS and locate the Derived Column transformation
-- Use the expression below to handle non-numeric postcode values before conversion.
-- Set the Derived Column expression as follows:
(DT_I4)(IS(postcode) ? 0 : ISNUMERIC(postcode) ? (DT_I4)postcode : -1)
-- Explanation:
-- This expression first checks if postcode is , assigning it to 0 if true
-- If not , it checks if postcode is numeric; if true, converts to DT_I4
-- Non-numeric postcodes will receive a default value of -1

-- This T-SQL script validates the error handling in sp_HandlePostcodeConversion
DECLARE @TestCases TABLE (Postcode NVARCHAR(10), ExpectedResult VARCHAR(50));
INSERT INTO @TestCases VALUES ('12345', 'Valid'), ('ABCDE', 'Invalid'), (, 'Invalid');
DECLARE @TestPostcode NVARCHAR(10), @Expected VARCHAR(50), @Result VARCHAR(50);
DECLARE TestCursor CURSOR FOR SELECT Postcode, ExpectedResult FROM @TestCases;
OPEN TestCursor;
FETCH NEXT FROM TestCursor INTO @TestPostcode, @Expected;
WHILE @@FETCH_STATUS = 0
BEGIN
    BEGIN TRY
        EXEC sp_HandlePostcodeConversion @TestPostcode;
        SET @Result = 'Valid';
    END TRY
    BEGIN CATCH
        SET @Result = 'Invalid';
    END CATCH;
    PRINT 'Postcode: ' + IS(@TestPostcode, '') + ' - Expected: ' + @Expected + ' - Result: ' + @Result;
    FETCH NEXT FROM TestCursor INTO @TestPostcode, @Expected;
END;
CLOSE TestCursor;
DEALLOCATE TestCursor;

Managing Data Conversion Failures in SSIS for Better Data Integrity

When working with SQL Server Integration Services (SSIS), the DTS_E_INDUCEDTRANSFORMFAILUREONERROR error is one of the more common challenges that data engineers face, especially when transforming data between types. This error often arises when non-integer data enters an integer-only column, such as when handling postcode fields. In such cases, SSIS attempts to transform these values using a Derived Column operation, which applies a defined formula or data type conversion. However, any invalid entry, like a text-based postcode or value, can result in an unexpected failure. Knowing how to handle this transformation issue is crucial for ensuring data reliability and preventing unnecessary disruptions in data flow.

One effective way to handle this issue is by configuring error-handling strategies within the SSIS package, such as using the Configure Error Output settings. In SSIS, this option allows the developer to specify what should happen to rows that produce errors. Instead of failing the entire process, rows with issues can be redirected to an error log or replaced with a default value. This approach keeps the process running, allowing the data team to review and clean up problematic rows post-process. For example, rows with invalid postcodes can be sent to a separate staging table for further review rather than blocking the entire data pipeline. 📈

Additionally, implementing conditional transformations within the SSIS package can be very beneficial. For instance, you could apply an Expression in the Derived Column transformation that checks if the postcode is numeric before attempting to convert it. This conditional approach minimizes errors by filtering out data that doesn’t meet specific criteria, reducing the need for extensive error handling after data transformation. By combining these strategies—configuring error outputs, redirecting problematic rows, and applying conditional transformations—developers can create more resilient SSIS packages that maintain data integrity and reduce manual correction needs.
